Alpine 12ED Electric Hybrid Tube Bender
Enhance your bending capabilities with the Alpine 12ED, a versatile and compact bender designed to tackle complex bending tasks with ease. This model is perfect for industries that require high precision in smaller tubing, such as electronics or small machinery manufacturing.
Key Features:
- Compact Double Stack Capability: Ideal for precise bending of small diameter tubes.
- Hybrid Efficiency: Combines the best of electric precision and hydraulic power.
- High Precision and Control: Delivers accurate bends with an advanced control system.
- Energy-Efficient Operation: Designed to reduce energy use while maximizing productivity.
Brand:
Alpine
Model:
12ED
Condition:
New
Not sure what Machine, Parts, or Tooling you need? We can help!
Standard Machine and Accessories:
- Features a user-friendly Master IV Controller with a touch screen interface.
- Right and left-hand bending capabilities for enhanced flexibility.
- Includes safety features like a Safety Mat and automatic lubrication for maintenance ease.
Upgrade Options:
- Dynamic Visual Simulation Software to aid in setup and avoid potential collisions.
- AMRU (Anticipate Mandrel Retraction Unit) and AML (Auto Mandrel Lubrication) for operational enhancements.
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | |
| 12ED | 12 x 1.0 | 0.5 x 0.039 | Dec-55 | 0.47 - 2.16 | 1000 | 39.37 | 3700 x 1100 x 1300 | 145.6 x 43.3 x 51.1 | 1400 | 3080 | More Info |
| 18ED | 18 x 1.6 | 0.71 x 0.062 | Oct-80 | 0.39 - 3.15 | 1200 | 47.24 | 4030 x 1200 x 1350 | 158.6 x 47.2 x 53.1 | 2500 | 5500 | More Info |
| 25ED | 25.4 x 1.5 | 1.0 x 0.059 | 15 - 120 | 0.59 - 4.72 | 1500 | 59.05 | 4800 x 1400 x 1350 | 168.9 x 55.1 x 53.1 | 3000 | 6600 | More Info |
| 30ED | 30 x 2.0 | 1.18 x 0.079 | 15 - 120 | 0.59 - 4.72 | 2200 | 86.61 | 5500 x 1500 x 1500 | 216.5 x 59.1 x 59.1 | 4000 | 8800 | More Info |
| 38ED | 38.1 x 1.8 | 1.5 x 0.071 | 25 - 150 | 0.98 - 5.9 | 2200 | 86.61 | 4200 x 900 x 1400 | 165.3 x 35.4 x 55.1 | 2080 | 4576 | More Info |
| 50ED | 50.8 x 2.0 | 2.0 x 0.079 | 30 - 220 | 1.18 - 8.66 | 2500 | 98.43 | 4650 x 1200 x 1500 | 183.1 x 47.2 x 59.0 | 3100 | 6820 | More Info |
| 65ED | 65 x 2.0 | 2.56 x 0.079 | 35 - 250 | 1.38 - 9.84 | 2500 | 98.4 | 6150 x 1650 x 1500 | 242.1 x 64.9 x 61.0 | 3800 | 8360 | More Info |
| 80ED | 80 x 2.5 | 3.15 x 0.098 | 40 - 280 | 1.57 - 11.0 | 3500 | 137.8 | 6350 x 1750 x 2050 | 250 x 68.8 x 80.7 | 5600 | 12320 | More Info |
| 100ED | 100 x 3.0 | 4.0 x 0.118 | 30 - 300 | 1.18 - 11.18 | 3500 | 137.8 | 7050 x 1550 x 1750 | 277.6 x 61.0 x 68.9 | 7500 | 16500 | More Info |
