Double Flare Upset Punch – 101422 Series – 1020-049 | 0.625 TOD
Double Flare Upset Punch for 5/8″ (0.625″ decimal) tube, 049 wall, driving the forming stroke in double-flare and upset hydraulic end-forming setups.
Out of stock
Brand:
Various
Model:
101422 Series
Condition:
New
Not sure what Machine, Parts, or Tooling you need? We can help!
This Double Flare Upset Punch is sized to 5/8″ (0.625″ decimal) tube, roughly 049 wall thickness, and produces the forming stroke needed for a proper double flare or upset end. Because it contacts the tube directly, punch condition has a direct effect on flare consistency and finish quality. It fits standard double-flare tooling setups used across end finisher shops. It is part of the 101422 series; compatible with DF tube end forming machines, and is a good fit for shops standardizing their tube and pipe end-forming tooling.
Series: 101422
Tube Outside Diameter (TOD) -Fractional Inches: 5/8″
Tube Outside Diameter (TOD) – Decimal Inches: 0.625
Tip No: 1020
Wall Thickness: 049
Machine Compatibility: DF
